Our Encapsulated Glazing System (EGS)
Our proprietary Encapsulated Glazing System delivers superior performance for specifically for oak-framed glazed structures. Developed from 30 years of expertise, EGS is backed by our comprehensive 12-year guarantee.
Our EGS has been engineered specifically for green oak frames, solving the traditional challenges of glazing with this natural material. The system allows glazed units to effectively float on the outside of the frame while maintaining a seamless, integrated appearance.
System Components
- Drip-profiled, air-dried oak capping, specially conditioned for exterior use
- Advanced spacer bars and routered drainage channels
- Weather strips and high plasticity sealant
- EPDM rubber seals and protective flashing
- Dedicated cavity for humidity venting and additional insulation
Key Benefits
- Superior weather protection against leakage around glass and through the oak frame
- Enhanced insulation properties with minimal cold bridging
- Accommodates natural oak movement while maintaining seal integrity
- Compatible with various glass specifications including acoustic glass and triple glazing
- TRADA-recognized design principles
- Combines robust performance with authentic oak character
Technical Specifications
- Standard specification: 28mm toughened glass
- Argon gas-filled cavity for superior insulation
- EPDM black rubber glazing tape bedding
- Flexible system design to accommodate green oak movement
- Optional additional insulation capabilities
Installation & Guarantee
Installation solutions for both oak frames and glazing can be found through our network of specialists. Every EGS installation is covered by our comprehensive 12-year guarantee, reflecting our confidence in the system's long-term performance.
For detailed specifications or to discuss your project requirements, contact us today.
